Swc-bh standard telescopic welded universal coupling

Swc-bh standard telescopic welded universal coupling is a commonly used coupling. The characteristics of the structure can be used to make the continuous rotation of two axes with the same angular velocity, which is not at the same axis or the axis has a large Angle of fold or moves in the axial direction, and the torque and motion can be transmitted reliably. Widely used in metallurgy, lifting, engineering transportation, mining, oil, shipping, coal, rubber, paper machinery and other heavy machinery industries in the mechanical shaft system transfer torque.

Swc-bh standard telescopic welded universal coupling has the following characteristics:

First, has the big Angle compensation ability.

Ii. Compact and reasonable structure. The swc-bh is designed with integral forkhead for reliability of the vehicle.

Iii. Large carrying capacity. Compared with other types of coupling shafts with the same rotary diameter, the torque transmitted by them is large, which is advantageous to the supporting range of mechanical equipment with limited rotary diameter.

High transmission efficiency. Its transmission efficiency up to 98- 99.8%, for high - power transmission, energy - saving effect.

Stable delivery, low noise, easy installation and maintenance.
